Wemo maker wiring diagram nov 19 the belkin wemo maker lets you control low voltage electronic devices with an android or ios connected to the sensor input of the wemo maker as shown in the diagram. Industry standard ttl 5v sensors are readily available.
Wemo Maker Brings The Fun Of Experimentation To Ios Engadget
Wemo maker sensor wiring. There was already a 120v wall outlet and all the items needed to keep the wemo maker in a climate controlled environment. Using your wire strippers strip away approximately ¼ from one end of both of your sprinklers ac power pack cables. Note that all three sensor override modes standby automatic and manual on cannot be remotely selected with a single wemo maker. Attach one of your sprinklers solenoid wires to the other relay terminal. Knowledge of electrical wiring required. Works with ifttt for customization and unique use cases.
Interconnecting wire routes may be shown approximately where particular receptacles or fixtures must be on a common circuit. Wired wemo maker provides a mechanism to connect almost any electrical device around your home to the internet with no programming knowledge required. Control nearly any low voltage electronics device via smartphone or tablet with free wemo app. The wemo maker can be wired to control the sensor in one of two ways as shown. Make sure your wemo maker and the device yourre about to install are disconnected from any power sources. Wemo maker garage door with notification siri 6 steps architectural wiring diagrams perform the approximate locations and interconnections of receptacles lighting and long lasting electrical facilities in a building.
Once connected the wemo maker allows you to monitor a variety of 5v digital sensors. Relatively easy to set up. However by placing the sensor into manual on mode using the override switch on the side of the sensor and wiring standby to the wemo maker. Use triggers from a variety of sensors with the wemo maker. You can connect almost anything that can be controlled with a low voltage switch or relay. Connect the relay leads.
Not compatible with amazon echo. Connect the sensor leads. Do not connect any device with voltage higher than 24vac at 1 amp or 12vdc at 2 amps. The wemo maker has simple screw terminals for switch and sensor connections. 15 attach either of these stripped wires to one of the wemo maker relay terminals using your phillips head screwdriver. The wemo maker can be wired to control.
When released the sensor will revert to automatic mode. An ideal tool for hobbyists who have wiring knowledge and enjoy taking electronics apart the wemo maker can connect to nearly any device controlled with a dc switch 24v dc at 1 amp or 12v ac at 2 amp. 5vdc at 100mamps out max. Wemo maker can be used as a controller a sensor or a manager. The unit can be wired to select standby mode or to select manual on mode. I ran both the magnetic door sensor wiring added the 22 2 wiring for length as well as a cat5 cable i had connected to the garage door opener ports red white on the garage door to my master closet.
