Electrical components such as your map light radio heated seats high beams power windows all have fuses and if they suddenly stop working chances are you have a fuse that has blown out. Diagram of the fuse box under the hood.
Db1cf Under Dash Fuse Diagram For 96 Honda Civic Ex Wiring
Under dash fuse box honda civic. Under dash fuse box is located under the drivers side instrument panel. The under hood fuse box is located on the passengers side next to the battery. Engine coolant blower motor relay. If your civic is experiencing electrical problems you should always check the fuses first because they are relatively easy to check and cheap to change. 1997 honda civic fuse layout 1997 honda civic fuse layout 1997 honda civic fuse layout for under dash fuse box. Location and descriptions of the fuses of the under dash fuse box for 17l 2001 2005 honda civic dx ex and lx.
Interior fuses fail frequently. The fuse box under the hood is located next to the battery in the engine compartment. If you need to see the under hood fuse box illustrationfuse descriptions go here. 1 not used 2 not used 3 10a rear wiperwasher security system option vehicles pre wired for accessory security system 4 10a right headlight drl control unit canada 5 10a left headlight drl control unit canada 6 security. Under hood fuserelay box 2001 2004 17l honda civic. The fuse box is located on the driver side of the dash below the steering column.
Figure 2 is a table containing the fuse number the rating and what that fuse does. Under dash fuserelay box page 01 2007 access our honda accord civic s2000 2007 2008 fuse relay boxes 2007 repair guide by creating an account or signing into your autozone rewards account. Enter your vehicle details. Figure 1 is the layout of your interior fuse panel which is located under the dash. For the honda civic 2001 2002 2003 2004 20052006 model year. Under the hood fuse box.
For the fuse descriptions of the under hood fuse box go here. In the table below youll find the fuse location and description of the fuses of the under dash fuse box on the 16l 1996 2000 honda dx ex and lx. The diagram in figure 2a is the layout of the fuse box located under the hood. Once you sign in follow these instructions to access our repair guides. Honda civic 2006 fuse box diagram year of production. Engine compartment the under hood fuse box is on the drivers side next to the brake fluid reservoir.
Some hondas have multiple interior fuse boxes including in the trunk the video above will show you where the interior fuse box of your 2012 civic is. Add your vehicle in manage my vehicles. The interior fuse box is underneath the steering column. Click the view more button and then click vehicle repair guides select the chapter fuse relay boxes 2007 repair guide. For example if your radio stopped working youd need to test fuse number 23 and replace it with a new 15 amp fuse if found to be faulty. Under hood fuserelay box 1996 2000 16l honda civic.
2006 engine compartment fuse box number ampere rating a circuits protected 1 100 main fuse 70 eps 2 80 option main 50 ignition switch main 3 30 abs 30 abs 4 50 headlight main 40 power window main 5 not used 6 20 sub.
