Another common type is a float that raises a rod to actuate a microswitch. The mercury displacement switch uses a plunger that dips into a pool of mercury raising the level in the container to contact at least one electrode.
How To Affix A Counterweight To A Float Switch T T Pumps
How does a mercury float switch work. When the float raises the magnet to the reed switch it closes. New float switch working principle float switches and water level controls usually start out closed meaning there are no alarms that need to be triggered because the water level is at the predetermined height. Description the eco float is a mercury free float switch for controlling liquid levels in a variety of applications. The sensor probes actually act as their own sensors and do not pass electricity through the probes which keeps them from fouling degrading and deteriorating. In a float switch the magnetic reed switch is hermetically sealed in a stem most often made from plastic or stainless steel. This design is used in relays in industrial applications that need to switch high current loads frequently.
One pattern uses a reed switch mounted in a tube. A float containing a magnet surrounds the tube and is guided by it. One type of float switch uses a mercury switch inside a hinged float. Once the cooling tower starts using the water for its industrial processes the water level starts dropping. How new float switches work water level controls float switches work by using probes instead of float switches. The float encases a sealed magnet which moves up and down the length of the stem as a fluid level rises and falls.
A snap action switch is activated by a steel ball rolling back and forth within a switching tube in a plastic float housing. There is a minimum differential between on and off of approximately 35 inches.
